NANOCELL foam is extra low modulus high density polyurethane foam sheet, which has shock absorption
and low frequency vibration damping. Also It is very soft, good conformability and sealability against irregular surface.
No corrosive gases are generated and gas generation less than 0.5%. It is consist in their unique cell structure
and the average cell size is about 100 microns. Which has high density and uniformity.
They maintain excellent resistance
to compression set, which enables durable, long-term performance for gasketing. Covered with slip coating, both sides of
the foam excel in slipping. |
|
|
|
| Item |
Unit |
Test Method |
SOFT NANAOCELL FOAM |
| Material |
|
Polyurethane Foam |
| Thickness |
MM |
Thickness Gauge |
6.0±5% |
| Color |
|
Visual |
Black |
| Density |
g/㎤ |
ASTM 3574 |
0.24±10% |
| Tear Strength |
kg/cm |
ASTM D624 |
1.2±10% |
| Hardness |
Shore "oo" |
ASTM D2240 |
34~37 |
| Tensile Strength |
kg/㎠ |
ASTM 3574 |
3±10% |
| Elongation |
% |
ASTM 3574 |
120±20 |
| Compression Set |
% |
ASTM 3574 |
5.8±10% |
| 25%Compression Force | kPa |
ASTM D1056 |
0.3±10% |
| UV Resistance |
|
ASTM G53-95 |
Good |
Dimensional Stability
( % max. change) |
20hrs. @60℃ in 80% moisture |
±2 |
Resilience
(Ball Rebound Tester) |
|
ASTM D2632-92 |
5±10% |
| Corrosion Resistance |
|
AMS 3568 |
Pass |
| Ozone Resistance |
|
GM4486P |
Pass |
Outgassing
(total mass loss) |
|
ASTM E595 |
≤ 0.5 |
|
| |
|
|
|
